Pneumatic Bellow Type Cylinders BRB Series

BRB Bellow Type Cylinders, renowned for their versatility with a stroke range of 26-100 mm and a flexible rolling bellow design. Operating on a single-acting principle, these cylinders retract seamlessly without pressure, ensuring efficient performance. Designed to endure diverse conditions, the working pressure spans a range specified in the accompanying table, while the ambient temperature tolerance extends from -30 to 90 °C. Utilising compressed air as the medium, these cylinders can accommodate a maximum tilt angle of 15°. Forces are determined at a pressure of 6 bar, and the weight varies as per the specifications in the provided table. Explore the comprehensive capabilities of BRB Bellow Type Cylinders, your reliable solution for dynamic pneumatic applications.
Shop Help Me

Key Features

Key features and benefits of BRB Bellow Type Cylinders.
1

Key Features

The innovative single-acting functional principle, complemented by a flexible rolling bellow, ensures seamless retraction without the need for external pressure, enhancing operational efficiency and reliability.
2

Key Features

With a stroke varying from 26 to 100 mm, BRB Bellow Type Cylinders offer adaptability for a range of pneumatic applications, providing precision and flexibility in motion.
3

Key Features

Engineered to thrive in challenging environments, these cylinders showcase a broad working pressure range specified in the accompanying table, and their ability to function across temperatures from -30 to 90 °C, making them ideal for diverse industrial settings.

Range of Cylinders

Need More Dimensions?

We provide comprehensive technical drawing services for pneumatic cylinders, with skilled artists ready to create the drawings you require. Simply let us know your specifications and needs.
Contact Us

Cylinder Standards

Functional Principle: Single-acting, retracted without pressure
Ambient Temperature Range: -30°C to 90°C
Working Pressure Range: 0 - 8 Bar
Medium: Compressed Air
Version: Flexible Rolling Bellow
Stroke Range: 26 - 100

FAQs

BRB Bellow Type Cylinders are hydraulic or pneumatic cylinders that use a bellows mechanism to convert fluid or air pressure into linear motion. The bellows design allows for precise control and durability in various applications.

BRB Bellow Type Cylinders find applications in a wide range of industries, including manufacturing, automotive, aerospace, pharmaceuticals, and more, due to their versatility and reliability.

These cylinders offer advantages such as compact design, resistance to contamination, high precision, and suitability for harsh environments. They are also maintenance-friendly.

Yes, BRB Bellow Type Cylinders can be designed with materials and coatings that make them suitable for use in corrosive environments, ensuring long-lasting performance.

Selecting the right cylinder involves considering factors like load capacity, stroke length, operating pressure, environmental conditions, and specific application requirements. Consult with one of our experts for guidance.

Regular maintenance includes checking for leaks, inspecting the bellows for wear, and ensuring that the cylinder remains properly lubricated. Refer to the manufacturer's guidelines for detailed maintenance instructions.
