ISO 15552

Emerson ISO 15552 Standard Pneumatic Cylinders meticulously adhere to the stringent specifications delineated in ISO 15552, a comprehensive standard that meticulously delineates metric series dimensions encompassing basic designs, mounting options, and associated accessories. This overarching standard assumes a pivotal role in guaranteeing the seamless interchangeability of both single and double rod pneumatic cylinders. By establishing a uniform framework for dimensions, ISO 15552 ensures compatibility across a diverse spectrum of applications and industries, facilitating a high degree of versatility in pneumatic system design and implementation.

TRB Series

The AVENTICS™ Series TRB Tie rod cylinders offer a versatile solution with piston diameters ranging from 32 mm to 125 mm. These cylinders feature advanced pneumatic cushioning and additional elastic cushioning for enhanced performance. They also come with a wide range of scraper modules, and thanks to the modular system, you can easily change the scraper on the cylinder, reducing service intervals significantly. With a plethora of variants and accessories accessible in the configurator, these cylinders provide flexibility and customization options to suit your specific needs.Upgrade your pneumatic systems with AVENTICS™ Series TRB Tie rod cylinders for optimal performance and efficiency.

Standards: ISO 15552
Working Pressure Range: 1.5 - 10 Bar
Temperature Range: -20°C to 80°C
Maximum Particle Size: 50 µm
Piston Force Pressure: 6.3 Bar
Materials: Aluminium (Anodised), Stainless Steel (Galvanised), Die-cast Aluminum, Polyurethane
Find Out More

ITS Series

The AVENTICS™ Series ITS Tie rod cylinders offer impressive capabilities, capable of moving up to five tons with ease. These ISO 15552 cylinders cover a wide stroke range, from just a few centimeters to a substantial 2700 mm, making them suitable for a variety of applications. Their modular sealing system allows for customised solutions, ensuring efficient operation while minimising maintenance. Designed with materials optimisation in mind, these cylinders are built to last.

Standards: ISO 15552
Working Pressure Range: 2 - 10 Bar
Temperature Range: -20°C to 80°C
Maximum Particle Size: 50 µm
Piston Force Pressure: 6.3 Bar
Materials: Aluminium (Anodised), Stainless Steel (Galvanised), & Acrylonitrile Butadiene Rubber
Find Out More

CCL-IS Series

The AVENTICS™ Series CCL-IS Standard cylinders offer hassle-free maintenance with their easily cleanable anodized surfaces. Perfect for food applications, these cylinders come with NSF-H1 approved scrapers and lubricants. Hygiene is a top priority, with protective caps for unused mounting holes. With a range of eight sizes, covering piston diameters from 25 mm to 125 mm, these cylinders fit various needs. You can also choose between elastic or pneumatic cushioning. Plus, the option to configure air connections on the rear cover enhances flexibility in designing your system's tubing concept.

Standards: ISO 15552
Working Pressure Range: 1.5 - 10 Bar
Temperature Range: -20°C to 80°C
Maximum Particle Size: 50 µm
Piston Force Pressure: 6.3 Bar
Materials: Aluminium (Anodised), Stainless Steel, & Polyester
Find Out More

General Information

ISO 15552 Pneumatic Cylinders

ISO 15552 Pneumatic Cylinders are among the most widely used standard actuators in industrial automation. They are designed with standardized mounting dimensions and stroke lengths, allowing for full interchangeability across brands and systems. These cylinders are typically used in medium to heavy-duty applications, thanks to their durable build and wide range of bore sizes.

The ISO 15552 standard replaces the earlier ISO 6431, offering enhanced precision and tighter tolerances, while still remaining backward compatible. These profile cylinders are perfect for systems that demand reliable, consistent force delivery and flexibility in mounting options.

Commonly found in manufacturing lines, packaging equipment, automotive assembly, and material handling systems, ISO 15552 cylinders provide long-lasting performance with simplified integration and easy maintenance.

FAQ'S

1. What is an ISO 15552 pneumatic cylinder?
An ISO 15552 cylinder is a standardised pneumatic actuator designed for industrial use, with mounting dimensions and stroke lengths that conform to international ISO specifications. It offers full interchangeability with other ISO 15552-compliant cylinders, regardless of the manufacturer.


2. What applications are ISO 15552 cylinders suitable for?
These cylinders are commonly used in automated manufacturing, packaging machinery, material handling, automotive assembly, and other medium- to heavy-duty environments where durability and consistent force are required.


3. What sizes are available in ISO 15552 cylinders?
They typically come in bore sizes from 32 mm up to 320 mm, with a wide range of stroke lengths available to match the specific needs of your application.


4. How does ISO 15552 differ from ISO 6431?
ISO 15552 is the modern replacement for ISO 6431. It includes improved dimensional tolerances and more refined specifications, while maintaining backward compatibility with ISO 6431 cylinders and mounting accessories.


5. Can ISO 15552 cylinders be customised?
Yes. While ISO 15552 defines the external dimensions for standardisation, manufacturers like Emerson often offer custom stroke lengths, seals, materials, and sensor compatibility to meet specific application needs.
