Pneumatic Double Piston Type Cylinders TWC Series

Discover our cutting-edge TWC Double Piston Type Cylinders, ranging from Ø 10 to 32 mm. These double-acting cylinders boast a magnetic piston for enhanced efficiency. The elastic cushioning ensures optimal performance within a working pressure range specified in the table below. Operating flawlessly in temperatures from 0 to 60 °C, these cylinders utilise compressed air with a max particle size of 5 µm and an impressively low oil content of 0-1 mg/m³. Elevate your pneumatic systems with reliability and precision, as these cylinders deliver exceptional functionality across diverse applications.

Key Features

Key features and benefits of TWC Double Piston Type Cylinders.
1

Key Features

Benefit from the advanced functionality of our TWC Double Piston Type Cylinders, offering double-acting capabilities for efficient and responsive operation.
2

Key Features

Experience enhanced productivity with the inclusion of a magnetic piston, ensuring optimal performance and reliability in your pneumatic systems.
3

Key Features

The cylinders feature elastic cushioning, providing precise control and smooth deceleration within the specified working pressure range, contributing to overall system efficiency.

Need More Dimensions?

We provide comprehensive technical drawing services for pneumatic cylinders, with skilled artists ready to create the drawings you require. Simply let us know your specifications and needs.
Contact Us

Cylinder Standards

Functional Principle: Double-acting
Ambient Temperature Range: 0°C to 60°C
Working Pressure Range: 1.5 - 7 Bar
Maximum Particle: 5 µm
Medium: Compressed Air
Stroke Range: 10 - 100
Bore Diameter: Ø 10-32 mm

FAQs

TWC Double Piston Type Cylinders are hydraulic or pneumatic devices used in various industrial applications to generate linear motion. They work by utilizing two pistons within a single cylinder to achieve enhanced force and precision.

The primary advantages include increased force output, improved stability, and precise control, making them ideal for applications requiring high-performance linear motion.

These cylinders find applications in industries such as manufacturing, automotive, aerospace, and heavy machinery, where precise and powerful linear motion is essential.

Yes, many manufacturers offer custom design options to tailor these cylinders to the specific requirements of your application, ensuring optimal performance.

Materials like stainless steel, aluminium, and high-strength alloys are commonly used to ensure durability and resistance to harsh environments.

Pneumatic Double Piston Cylinders: An Essential Guide for Efficiency and Precision

Explore the mechanics and applications of Double Piston Pneumatic Cylinders in this comprehensive blog. Explore and learn today through the link below.
Learn More
